Spareparts VENTED HEATERS

Pos. Description BV 440 <97

1 INLET GRILLE 4031.189

2 ELASTIC PLATE M5 4031.182

3 SCREW TC M5X16 S/R

4 1.5 HP 3-MOTOR 4031.253

5 45 UF CONDENSER 4031.212

6 FAN Ø 550 MM 36 4031.263

7 WASHER 6X24X2 S/R

8 ELASTIC GROVER WASHER Ø 6 S/R

9 SCREW TE M6X16 S/R

10 CABLE FASTENER PG 11 S/R

11 CABLE PROTECTION Ø 18 S/R

12 KABEL 4X1 (MT) S/R

13 AXLE 4031.157

14 WHEEL Ø 250X50 4031.134

15 WHEEL HOLDER Ø 25 4031.177

16 BEARING 4031.183

17 GASKET 4031.201

18 BURNER SUPPORT S/R

19 1" IRON PLUG S/R

20 BURNER COVER 4031.185

21 TOP COVER BURNER 4031.190

22 SUSPENDING RING SCREW M10 4031.332

23 THERMAL ISULATION 4031.203

24 CHIMNEY INSPECTION DOOR S/R

25 COMBUSTION CHAMBER S/R

26 1,5 HP FAN 3- S/R

27 CONNECTION 90" 1/4 MF 4031.222

28 FILTER HEAD S/R

29 FILTER OR S/R

30 UPPER SEAL 4031.181

31 FILTER CARTRIDGE S/R

32 LOWER SEAL S/R

33 FILTER HOUSING S/R

34 FILTER 1/4 S/R

35 BITHERMOSTAT TTCA 4031.194

36 EL. COMPONENTS BOX 4031.261

37 TERMINAL BOARD 6MM 2 S/R

38 CONTROL KNOB 1-0-2 4031.268

39 FUSE HOLDER 4031.206

40 6,3 A FUSE (5X20) 4031.102

41 10 A FUSE (5X20) 4031.101

42 RED PILOT LAMP Ø 10 4031.260

43 4P + G SOCKET 4031.086

44 4P + G PLUG 4031.087

45 3P + G SOCKET 4031.088

46 3P + G PLUG 4031.089

47 EL. WIRE 5X1.5 (MT) S/R

48 EL. COMPONENTS DRAWER 4031.198

49 FUSE HOLDER UN. (5X20) 4031.188

S/R = Parts Available by Special Request Only

186
