158

Spareparts MASTER MANUAL GAS HEATERS 70 kW

Pos. Code NR Description

1 4160.759 OUTLET GRID

2 4160.957 COMBUSTION CHAMBER

3 4161.030 YELLOW COVER RAL 1006

4 4160.715 PLASTIC HANDLE

5 4160.959 FAN

6 4160.958 ELECTRIC MOTOR

7 4160.758 INLET GRID

8 4161.012 SUPPORT ELECTRIC MOTOR

9 4160.744 PLATE BURNER

10 4160.731 IGNITION ELETTRICAL FOLDER

11 4160.708 SUPPORT FOR THERMOSTAT

12 4160.636 SAFETY THERMOSTAT 90°

13 4160.953 INTERRUPTED THERMOCOUPLE

14 4160.627 ELASTIC WASHER

15 4160.962 NOZZLE 1/4" - 1/8"

16 4160.963 ELECTROVALVE

17 4160.964 NIPPLES REDUCER

18 4160.700 GAS INLET NOZZLE 3/8 M - 1/8 M

19 4160.688 SAFETY GAS VALVE

20 4160.701 RING NUT M12X0,75

21 4160.684 GAS COCK

22 4160.646 GROMMET 16-30-22

23 4160.951 SUPPORT BURNER

24 4160.950 BASE

25 4160.637 SWITCH

26 4160.638 COVER SWITCH

27 4160.631 ELECTRIC CABLE

28 4160.635 KEEPER WIRE DEVICE PA 107

29 4160.641 PIEZO IGNITOR

30 4160.640 ADAPTER FOR PIEZO IGNITOR

31 4160.639 RIVET POP

32 4160.967 90° DEGREE ELBOW 1/8"

33 4160.768 SUPPORT GAS NOZZLE

34 4160.770 GAS NOZZLE

35 4160.767 COPPER EXTENDIN VALVOLE-NOZZLE

37 4160.676 GAS BURNER
