Spareparts VENTED HEATERS from 2002

Pos. Description BV 100 BV 160 BV 280

MAIN BODY

1 FRAME HANDLE S/R S/R S/R

2 FRAME BEARING S/R S/R S/R

3 OUTLET CONE 4031.278 4031.278 S/R

4 PLUG S/R S/R S/R

5 AXLE S/R S/R S/R

6 WHEEL 200 MM 4031.133 4031.133 -

6.1 WHEEL 250 MM - - 4031.134

7 WHEEL HOLDER 20 MM 4031.175 4031.175 -

7.1 WHEEL HOLDER 25 MM - - 4031.177

8 FUEL TANK 4031.004 4031.004 -

8.1 FUEL TANK - - 4031.006

9 DRAIN PLUG 4031.013 4031.013 4031.013

10 DRAIN PLUG OR S/R S/R S/R

11 TANK PLUG 4031.145 4031.145 4031.145

12 REAR INLET GRILL S/R S/R -

12.1 REAR INLET GRILL - - 4031.137

13.1 FAN 300MM 18 DGR 4031.270 - -

13.2 FAN 300MM 27 DGR - 4031.271 -

13.3 FAN 500MM 33 DGR - - 4031.272

14 GRUB SCREW S/R S/R S/R

15 MOTOR SUPPORT 4031.139 4031.139 4031.138

16 AIR FLAB S/R S/R S/R

17.1 COMBUSTION CHAMBER 4031.273 - -

17.2 COMBUSTION CHAMBER - 4031.274 -

17.3 COMBUSTION CHAMBER - - 4031.276

18 F LAME GUARD SHIELD S/R S/R S/R

19 BASE SX S/R S/R 4031.363

20 BASE DX S/R S/R 4031.364

21 LOWER BODY S/R S/R S/R

22 UPPER BODY S/R S/R S/R

23 UPPER BODY (REAR) S/R S/R S/R

24 CHIMNEY DIAM. 150 MM 4031.277 4031.277 4031.277

25 CABLE PROTECTION S/R S/R S/R

83 SCREW TC M5X16 S/R S/R S/R

84 SCREW TE 10X1/2" FR S/R S/R S/R

85 NUT M6 S/R S/R S/R

86 SLEEVE S/R S/R S/R

88 SCREW TE M6X16 S/R S/R S/R

93 SCREW TE 14X1/2" FR S/R S/R S/R

99 ELASTIC PLATE U42-032 S/R S/R S/R

102 SCREW TE M6X30 S/R S/R S/R

107 POWER CORD HOOK S/R S/R S/R

108 SUPPORT BAR - - S/R

109.1 YELLOW PLUG WHEEL DIAM.200MM S/R S/R -

109.2 YELLOW PLUG WHEEL DIAM. 250MM - - S/R

S/R = Parts Available by Special Request Only
